| Item | Specifications | |
| Antenna | Frequency Range | 698~960/1710~2690MHz |
| Polarization | Linear | |
| Gain | 2.5dBi（Zenith） | |
| V.S.W.R | ≤3.0 | |
| Impendance | 50Ω | |
| Mechanical | Cable | RG58 or others |
| Connector | SMA or others | |
| Radome Material | ABS | |
| Mounting Method | Screw | |
| Environmental | Operating Temperature | -40℃~+85℃ |
| Ingress Protection | IP65-IP67 | |
| Relative Humidity | Up to 95% | |
| Vibration | 10 to 55Hz with 1.5mm amplitude 2hours | |
| Environmentally Friendly | ROHS Compliant | |
