Item Specifications
4G LTE Antenna MAIN Frequency Range 698~960MHz/1710~2690MHz
V.S.W.R <3.0
Polarization Linear
Gain 2.5dBi(Zenith)
Impedance 50Ω
4G LTE Antenna AUX Frequency Range 698~960MHz/1710~2690MHz
V.S.W.R <3.0
Polarization Linear
Gain 2.0dBi(Zenith)
Impedance 50Ω
  Mechanical Cable RG174
Connector SMA or others
Material ABS
Mounting Method Screw
Environmental  Operating Temperature -40℃~+85℃
Relative Humidity Up to 95%
Ingress Protection IP67(exclude cable outlet)
Vibration 10 to 55Hz with 1.5mm amplitude 2hours
Environmentally Friendly ROHS Compliant
