MASWELL rectangular patch WiFi antenna, Frequency range 2400~2500MHz
Release time：2021/10/26
MASWELL's AN_W063 is a patch type WiFi antenna with peak gain of 3dBi in the operating frequency range of 2400~2500MHz. The antenna model is made of ABS antenna cover, which is strong and durable and can prolong the service life of the product and ensure the stability of the antenna performance. At the same time, the paste type installation method makes the antenna suitable for various surface installation and easy to conformal, especially suitable for equipment through the wall installation and vehicle conformal application.
Figure 1. Product Diagram
Features of AN_W063 ：
Frequency Range
2400~2500MHz
Polarization
Linearity
Gain
3dBi (Zenith)
Impedance
50Ω
PCB Area
104.6*15*1mm
Cable
RG 174 or other
Connector
SMA or others
Antenna Cover Material
ABS
Mounting Method
Adhesive
Customizable cables and connectors
Application of AN_W063 ：
Indoor CPE Devices
Router Signal Enhancement
IoT
Industrial Control
Instrumentation
