| Item | Specifications | |
| Antenna | Center Frequency | 1616-1626.5MHz |
| Band Width | 10.5MHz | |
| Polarization | RHCP | |
| Gain | 5dBic（Zenith） | |
| V.S.W.R | ＜1.5 | |
| Impendance | 50Ω | |
| Axial Ratio | 5dB(max) | |
| Mechanical | Cable | RG316 5m |
| Connector | SMA male | |
| Radome Material | ABS | |
| Mounting Method | Screw | |
| Environmental | Operating Temperature | -40℃~+85℃ |
| Relative Humidity | Up to 95% | |
| Ingress Protection | IP67 | |
| Vibration | 10 to 55Hz with 1.5mm amplitude 2hours | |
| Environmentally Friendly | ROHS Compliant | |
