MASWELL cost-effective entry 5G antenna, Coverage frequency range 698~3800MHz
Release time：2021/10/26
MASWELLl's entry-level 5G antenna AN_Master_003, with a frequency range of 698~3800MHz and a typical gain of 3.0dBi, supports almost all 5G, 4G LTE, 3G and WiFi bands worldwide. The product is compact, only D1.3*20cm, plug-and-play, no complicated installation.
This product is very cost effective and can be quickly introduced to current 5G, 4G and other types of systems and adapt to a large number of devices.
Figure 1. Product Diagram
Product Features of AN_Master_003 ：
Frequency Range
698~3800 MHz
Polarization
Linear
Gain
3.0dBi（typ.）
V.S.W.R
＜3.0
Impedance
50Ω
Connector
SMA Male
Application of AN_Master_003：
IoT
Vehicles
Industrial Equipment
Router
Video Surveillance
